AIR COMPRESSORS, RECIPROCATING LUBRICATED

2018 Compressed Air Systems B53V84-E, Machine # 9022

Compressed Air Systems B53V84-E - 2	Compressed Air Systems B53V84-E - 3	Compressed Air Systems B53V84-E - 5
Compressed Air Systems B53V84-E - 4	Compressed Air Systems B53V84-E - 1

Reference #:	9022
Machine Type:	Air Compressors
Year:	2018
Manufacturer:	Compressed Air Systems
Model:	B53V84-E
Control:
Condition:	Very Good
Under Power:	??
Code:	A2425
Specifications: Horsepower: 5 hp Flow at 175 psi: 19 cfm Tank: Vertical 80 gallons Voltage: 208-230-460 volts Phase: 3 Amp Draw at 230V: 16 Amps Amp Draw at 480V: 8 Amps Comments: Heavy duty two stage solid cast iron pump Disk and spring valves Bearings on both ends of the crank shaft Needle bearings and inserts on rods Industrial grade electric motor ASME tested powder coated steel tank 2 grove B width motor pulley All UL electrical controls Access to compressor valves without compressor head removal Auto start / stop Fully enclosed belt guard Centrifugal unloader Heavy duty air filters Swedish steel valves Torrington needle bearings Low oil monitor Magnetic starter mounted and wired Automatic tank drain Vibration pads Comments: Probably used for about 4 months and we have no need for this anymore
