LATHES, CNC, 2-AXIS, UNIVERSAL

2008 Toolmex TUR-930 MN/236, Machine # 4537

Toolmex TUR-930 MN-236 CNC Lathe - 1	Toolmex TUR-930 MN-236 CNC Lathe - 5	Toolmex TUR-930 MN-236 CNC Lathe - 4
Toolmex TUR-930 MN-236 CNC Lathe - 6	Toolmex TUR-930 MN-236 CNC Lathe - 3	4537

Reference #:	4537
Machine Type:	CNC Lathes
Year:	2008
Manufacturer:	Toolmex
Model:	TUR-930 MN/236
Control:	Fanuc 21iT
Condition:	Excellent
Under Power:	Yes
Code:	L2150
Capacity: Swing Over Bed Ways: 37.4'' Swing Over Cross Slide: 24.8" Maximum Turning Length: 236.22" Weight Between Centers: 11,000 lbs Weight Capacity on Chuck: 2,200 lbs Spindle Speeds, 2-Ranges (Variable): 4-1200 RPM Spindle Bore: 5.5" Spindle Nose Mount: D1-11 Spindle Drive Motor: 30/45 HP X & Z Axis Rapid Traverse: 235 IPM Quill Diameter: 4.9" Quill Stroke: 11.8" Quill Taper: #6 MT X-Axis Ballscrew: 1.57" Z-Axis Ballscrew: 2.48" Overall Dimensions: 335" x 118" x 95" Machine Weight: 28,200 Lbs. Machine Voltage: 460 Volts Equipped With: Fanuc 21iT CNC Control 25" Set-Tru Bison 3-Jaw Chuck 8-Position Sauter Turret (VDI 50) (3 Tool Holders Included) V Bed Ways Manual Pulse Generator Jorgensen Chip Conveyor Hydraulic Tailstock Steady Rest (13.4") Comments: About 400 hours of use. In plant, under power
